Proprietary aluminum alloy dorsal connector provides simplified push button attachment
Exclusive energy absorber design with nylon fused EVA cover limits user back discomfort.
Constant-force main spring produces smooth lifeline payout and retraction
Calibrated pawl locking system delivers ideal walking speed without nuisance lock-up
Lightweight and impact resistant nylon polymer housing provides greater durability
Versatile anchorage range from overhead up to 5′ below user’s dorsal D-ring
3/16″ galvanized steel cable lifeline with aluminum alloy rebar hook
Rebar hook features transverse load rated gate
Complies with ANSI Z359.14-2014
OSHA Compliant: Galvanized Steel Cable
Dorsal SRL Slide Connector: Aluminum Alloy
Leading Edge: Aluminum Alloy
Cable: 3/16″ galvanized steel; 3,400 lb min. static strength
Energy Absorber: Polyester tear-away
Anchorage Connector: Aluminum alloy; 5,000 lb min. static strength with 3,600 lb gate strength
Dorsal Connector: Aluminum alloy; 3,000 lb min.
Static Strength: 3,000 lb min.
ANSI SRL Class: Class B
Avg. Arrest Force: 900 lb
Max. Arrest Force: 1,800 lb
Max. Arrest Distance: 54″
ANSI User Capacity: 130 to 310 lb max.
OSHA User Capacity: 130 to 310 lb max.
